Hydrostatic Testing Machine | Pressure 0 - 100 bar | Compliant with National Standard 7186

Advanced industries require reliable pressure testing! The advanced hydrostatic testing device is a comprehensive solution for leak testing of components under pressure in various industries such as oil and gas, water and sewage, food, marine, and agriculture.

With 0.1 bar precision and ambient temperature control, minimize test errors and ensure the flawless quality of your products.

Compare Request Proforma Invoice

Product Specifications

Number of Ports	2,3,4,5,6
Maximum Input Power	1.2 + tank heater
Operating Temperature (Celsius)	10 ~ 40
Maximum Water Temperature (Celsius)	95
Maximum Air Pressure (Bar)	100
Minimum Test Duration (Seconds)	1
Maximum Test Duration (Hours)	1000
Data Output Report	PDF / EXCEL
Dimensions (WxDxH) Centimeters	7070180
Approximate Weight (Kilograms)	200
Power Consumption	380±10V, 50~60Hz, PE + N

Product Introduction

This device creates stable (non-pulsating or fluctuating) hydrostatic pressure in the tested sample, detecting leaks with 0.1 bar precision.
Corrosion-resistant 304 stainless steel body ensures the device’s durability and reliability in operational environments.
Hydrostatic pressure generation system technology with uniform pressure increase slope provides test conditions compliant with national standard 7186 and other international standards (ASME B31.3, EN 805).
Shock-free pressure generation with a linear increase of 0.1 bar/second.

Supported Standards

Iran National Standard: ISIRI 7186
International Standards: ISO 3459, ISO 11617, ASME Sec.VIII
Ability to customize test methods

Industrial Applications

Oil, gas, and petrochemical: Testing valves, transmission pipelines, and storage tanks
Water and wastewater: Testing polyethylene pipes, fittings, and high-pressure pumps
Food industry: Testing stainless steel tanks, heat exchangers, and processing lines
Maritime and shipbuilding: Testing ship components, cooling systems, and fuel tanks
Agriculture: Testing pressurized irrigation systems and sprayer pumps
